Ground Clearance (mm)
|
370 mm | 370 mm | 370 mm | 370 mm | 370 mm | 370 mm | 343 mm ↓ |
|
Ground Clearance (in.)
|
14.6 inches | 14.6 inches | 14.6 inches | 14.6 inches | 14.6 inches | 14.6 inches | 13.5 inches ↓ |
|
Displacement (cc)
|
349.70 cc | 349.70 cc | 349.7 cc | 349.7 cc | 349.7 cc | 349.7 cc | 349.7 cc |
|
Brakes - Rear Diameter (mm)
|
220 mm | 220 mm | - | - | - | - | |
|
Brakes - Rear Diameter (in.)
|
8.7 inches | 8.7 inches | - | - | - | - | |
|
Brakes - Front Diameter (mm)
|
260 mm | 260 mm | - | - | - | - | |
|
Brakes - Front Diameter (in.)
|
10.2 inches | 10.2 inches | - | - | - | - | |
|
Frame Type
|
25CrMo4 steel central-tube | 25CrMo4 steel central-tube | 25CrMo4 steel central-tube | 25CrMo4 steel central-tube | Central double-cradle-type 25CrMo4 steel | Central double-cradle-type 25CrMo4 steel | Central double-cradle-type 25CrMo4 steel |
|
Dry Weight
|
100.6 kg / 221.8 lbs | 100.6 kg / 221.8 lbs | 100.6 kg / 221.8 lbs | 100.6 kg / 221.8 lbs | 100.5 kg / 221.6 lbs ↓ | 100.5 kg / 221.6 lbs | 102.7 kg / 226.4 lbs ↑ |
|
Seat Height
|
960 mm / 37.8 in. | 960 mm / 37.8 in. | 950 mm / 37.4 in. ↓ | 950 mm / 37.4 in. | 950 mm / 37.4 in. | 950 mm / 37.4 in. | 948 mm / 37.3 in. ↓ |
|
Wheelbase
|
1,482 mm / 58.3 in. | 1,482 mm / 58.3 in. | 1482 mm / 58.3 in. ↑ | 1482 mm / 58.3 in. | 1482 mm / 58.3 in. | 1482 mm / 58.3 in. | 1482 mm / 58.3 in. |
|
Fuel Capacity
|
8.50 litres / 2.25 gallons | 8.50 litres / 2.25 gallons | 8.50 litres / 2.25 US gallons | 8.50 litres / 2.25 US gallons | 8.50 litres / 2.25 US gallons | 8.50 litres / 2.25 US gallons | 8.50 litres / 2.25 US gallons |
|
Suspension - Front
|
WP-USD, AER 48, ? 48 mm | WP-USD, AER 48, ? 48 mm | WP-USD, AER 48, Ø 48 mm | WP-USD, AER 48, Ø 48 mm | WP XACT-USD, Ø 48 mm | WP XACT-USD, Ø 48 mm | WP XACT-USD, Ø 48 mm |
|
Suspension - Rear
|
WP shock absorber with linkage | WP shock absorber with linkage | WP shock absorber with linkage | WP shock absorber with linkage | WP XACT Monoshock with linkage | WP XACT Monoshock with linkage | WP XACT Monoshock with linkage |
|
Colours
|
White/blue/yellow | White/blue/yellow | White/blue/yellow | White/blue/yellow | White/blue/yellow | White/blue/yellow | White/grey/yellow |
|
Clutch
|
Wet, DDS multi-disc clutch, Magura hydraulics | Wet, DDS multi-disc clutch, Magura hydraulics | Wet, DDS multi-disc clutch, Magura hydraulics | Wet, DDS multi-disc clutch, Magura hydraulics | Wet, DDS multi-disc clutch, Magura hydraulics | Wet, DDS multi-disc clutch, Brembo hydraulics | Wet, DDS multi-disc clutch, Brembo hydraulics |
|
Final Drive
|
Chain | Chain | Chain (final drive) | Chain (final drive) | Chain (final drive) | Chain (final drive) | Chain (final drive) |
|
Engine Lubrication
|
Forced oil lubrication with 2 Eaton pumps | Forced oil lubrication with 2 Eaton pumps | Forced oil lubrication with 2 Eaton pumps | Forced oil lubrication with 2 Eaton pumps | - | - | |
|
Tyres - Rear
|
140/80-18 | 140/80-18 | - | - | - | - | |
|
Primary Drive
|
5/8 x 1/4 | 5/8 x 1/4 | 5/8 x 1/4 | 5/8 x 1/4 | 5/8 x 1/4´ chain | 5/8 x 1/4´ chain | 5/8 x 1/4´ X-ring chain |
|
Rake
|
26.5° | 26.5° | 26.5° | 26.5° | 26.1° ↓ | 26.1° | 26.1° |
|
Power-to-Weight Ratio
|
0.5765 HP/kg | 0.5765 HP/kg | 0.5765 HP/kg | 0.5765 HP/kg | 0.5771 HP/kg | 0.5771 HP/kg | 0.5648 HP/kg ↓ |
