Ground Clearance (mm)
|
371 mm | 370 mm ↓ | 370 mm | 370 mm | 370 mm | 370 mm | 370 mm | 336 mm ↓ |
|
Ground Clearance (in.)
|
14.6 inches | 14.6 inches | 14.6 inches | 14.6 inches | 14.6 inches | 14.6 inches | 14.6 inches | 13.2 inches ↓ |
|
Fuel Control
|
DOHC | Double Overhead Cams/Twin Cam (DOHC) | Single Overhead Cams (SOHC) | Single Overhead Cams (SOHC) | Single Overhead Cams (SOHC) | Single Overhead Cams (SOHC) | Single Overhead Cams (SOHC) | Single Overhead Cams (SOHC) |
|
Displacement (ci)
|
27.42 cubic inches | 27.42 cubic inches | 27.42 cubic inches | 27.42 cubic inches | 27.45 cubic inches ↑ | 27.45 cubic inches | 27.45 cubic inches | 27.45 cubic inches |
|
Displacement (cc)
|
449.30 cc | 449.30 cc | 449.30 cc | 449.30 cc | 449.9 cc ↑ | 449.9 cc | 449.9 cc | 449.9 cc |
|
Comments
|
Swedish made bike. | - | - | - | - | - | - | Traction control. Two engine maps. |
|
Brakes - Rear Diameter (mm)
|
220 mm | 200 mm ↓ | 200 mm | 200 mm | - | - | - | |
|
Brakes - Rear Diameter (in.)
|
8.7 inches | 7.9 inches ↓ | 7.9 inches | 7.9 inches | - | - | - | |
|
Brakes - Front Diameter (mm)
|
260 mm | 260 mm | 260 mm | 260 mm | - | - | - | |
|
Brakes - Front Diameter (in.)
|
10.2 inches | 10.2 inches | 10.2 inches | 10.2 inches | - | - | - | |
|
Seat Height
|
992 mm / 39.1 in. | 960 mm / 37.8 in. ↓ | 960 mm / 37.8 in. | 960 mm / 37.8 in. | 950 mm / 37.4 in. ↓ | 940 mm / 37.0 in. ↓ | 940 mm / 37.0 in. | 939 mm / 37.0 in. ↓ |
|
Frame Type
|
Central tube frame made of chrome molybdenum steel tubing | 25CrMo4 steel central-tube | 25CrMo4 steel central-tube | 25CrMo4 steel central-tube | 25CrMo4 steel central-tube | 25CrMo4 steel central-tube | Central double-cradle-type 25CrMo4 steel | Central double-cradle-type 25CrMo4 steel |
|
Dry Weight
|
107.6 kg / 237.2 lbs | 102.4 kg / 225.8 lbs ↓ | 101.2 kg / 223.1 lbs ↓ | 101.2 kg / 223.1 lbs | 101 kg / 222.7 lbs ↓ | 101 kg / 222.7 lbs | 101 kg / 222.7 lbs | 102.8 kg / 226.6 lbs ↑ |
|
Brakes - Front
|
Single disc. Four-pot brake caliper | Single disc. Four-pot brake caliper | Single disc. Brembo twin-piston floating calliper | Single disc. Brembo twin-piston floating calliper | Single disc. Brembo twin-piston floating calliper | Single disc. Brembo twin-piston floating calliper | Single disc. Brembo twin-piston floating calliper | Single disc. Brembo twin-piston floating calliper |
|
Engine Detail
|
Reed intake. | - | - | - | - | - | - | |
|
Wheelbase
|
1,482 mm / 58.3 in. | 1,485 mm / 58.5 in. | 1,485 mm / 58.5 in. | 1,485 mm / 58.5 in. | 1485 mm / 58.5 in. ↑ | 1485 mm / 58.5 in. | 1485 mm / 58.5 in. | 1485 mm / 58.5 in. |
|
Brakes - Rear
|
Single disc. One-pot brake caliper, floating disc | Single disc. One-pot brake caliper, floating disc | Single disc. Brembo single-piston floating calliper | Single disc. Brembo single-piston floating calliper | Single disc. Brembo single-piston floating calliper | Single disc. Brembo single-piston floating calliper | Single disc. Brembo single-piston floating calliper | Single disc. Brembo single-piston floating calliper |
|
Fuel Capacity
|
7.50 litres / 1.98 gallons | 7.00 litres / 1.85 gallons ↓ | 7.00 litres / 1.85 gallons | 7.00 litres / 1.85 gallons | 7.00 litres / 1.85 US gallons | 7.00 litres / 1.85 US gallons | 7.00 litres / 1.85 US gallons | 7.20 litres / 1.90 US gallons ↑ |
|
Suspension - Front
|
WP Suspension Up Side Down 4CS | WP USD ? 48 mm 4CS closed cartridge ↑ | WP-USD, AER 48, ? 48 mm | WP-USD, AER 48, ? 48 mm | WP-USD, AER 48, Ø 48 mm | WP XACT-USD, Ø 48 mm | WP XACT-USD, Ø 48 mm | WP XACT-USD, Ø 48 mm |
|
Suspension - Rear
|
WP Monoshock with linkage | WP shock absorber with linkage | WP shock absorber with linkage | WP shock absorber with linkage | WP shock absorber with linkage | WP XACT Monoshock with linkage | WP XACT Monoshock with linkage | WP XACT Monoshock with linkage |
|
Fuel System
|
Injection | - | - | Carburettor | Carburettor | Carburettor. 44mm Keihin | Carburettor. 44mm Keihin | Carburettor. 44mm Keihin |
|
Colours
|
Blue/yellow | Blue/yellow/white | Blue/yellow/white | White/yellow/wblue | White/yellow/wblue | White/yellow/wblue | White/yellow/wblue | White/yellow/grey |
|
Clutch
|
Wet multi-disc clutch DDS / Brembo hydraulics | Wet, multi-disc clutch, Magura hydraulics | Wet, multi-disc clutch, Magura hydraulics | Wet, multi-disc clutch, Magura hydraulics | Wet, multi-disc clutch, Magura hydraulics | Wet, multi-disc clutch, Magura hydraulics | Wet, DDS multi-disc clutch, Brembo hydraulics | Wet, DDS multi-disc clutch, Brembo hydraulics |
|
Final Drive
|
Chain | Chain | Chain | Chain | Chain (final drive) | Chain (final drive) | Chain (final drive) | Chain (final drive) |
|
Warranty
|
2 Years | 2 Years | 2 Years | - | - | - | - | |
|
Engine Lubrication
|
Forced oil lubrication with 2 Eaton pumps | - | - | - | - | - | - | |
|
Tyres - Rear
|
140/80-18 | 140/90-18 | 140/90-18 | 140/90-18 | - | - | - | |
|
Primary Drive
|
520 X-Ring chain | 520 X-Ring chain | 520 X-Ring chain | 520 X-Ring chain | 520 X-Ring chain | 520 X-Ring chain | 5/8 x 1/4´ chain ↓ | 5/8 x 1/4´ chain |
|
Rake
|
26.5° | 26.5° | 26.5° | 26.5° | 26.5° | 26.1° ↓ | 26.1° | 26.1° |
|
Wheel Travel - Front
|
300 mm / 11.8 in. | 300 mm / 11.8 in. | 310 mm / 12.2 in. ↑ | 310 mm / 12.2 in. | 310 mm / 12.2 in. | 300 mm / 11.8 in. ↓ | 300 mm / 11.8 in. | 305 mm / 12.0 in. ↑ |
|
Wheel Travel - Rear
|
335 mm / 13.2 in. | 300 mm / 11.8 in. ↓ | 300 mm / 11.8 in. | 300 mm / 11.8 in. | 300 mm / 11.8 in. | 300 mm / 11.8 in. | 300 mm / 11.8 in. | 293 mm / 11.5 in. ↓ |
|
Ignition
|
Contactless, controlled, fully electronic ignition system with digital ignition timing adjustment | Keihin EMS | Keihin EMS | Keihin EMS | Keihin EMS | Keihin EMS | Keihin EMS | Keihin EMS |
|
Power-to-Weight Ratio
|
- | 0.6152 HP/kg | 0.6225 HP/kg | 0.6225 HP/kg | 0.6238 HP/kg | 0.6238 HP/kg | 0.6238 HP/kg | 0.6128 HP/kg ↓ |
