Key Specifications
Engine
Four stroke, V-Twin, Milwaukee-Eight 107, pushrod-operated, overhead valves with hydraulic, self-adjusting lifters, 4 valves per cylinder
Torque
146 Nm / 108 ft-lb @ 2750 rpm
Fuel Capacity
18.9 Litres / 5.0 US gal
Advertisement
Full 2021 Harley-Davidson Sport Glide Specifications
Year
2020 - 21
Make Model
Harley Davidson Sport Glide
Seat Height
Unladen: 680 mm / 26.8 in Laden : 653 mm / 25.7 in
Wheelbase
1625 mm / 64 in
Ground Clearance
120 mm / 4.7 in
Height
1120 mm / 44.1 in
Length
2325 mm / 91.5 in
Width
960 mm / 37.8 in
Dry Weight
304 kg / 670 lbs
Fuel Capacity
18.9 Litres / 5.0 US gal
Oil Capacity
4.7 Litres / 5 US qt
Wet Weight
317 kg / 699 lbs
Displacement
1746 cc / 107 cu-in
Engine Detail
Four stroke, V-Twin, Milwaukee-Eight 107, pushrod-operated, overhead valves with hydraulic, self-adjusting lifters, 4 valves per cylinder
Bore x Stroke
100 x 111 mm
Compression Ratio
10.0:1
Cooling System
Air cooled
Exhaust
2-into-1, catalyst in muffler
Fuel Induction
Electronic Sequential Port Fuel Injection (ESPFI)
Ignition
Single-fire, non-wasted, map-controlled spark ignition
Lubrication
Pressurized, dry-sump with oil cooler
Starter
Electric
Clutch
Mechanical, 10 plate wet, assist & conventional
Final Drive
Belt, 32/66 ratio
Gear Ratios
1st 9.311 / 2nd 6.454 / 3rd 4.793 / 4th 3.882 / 5th 3.307 / 6th 2.79:1
Primary Drive
Chain, 34/46 ratio
Transmission / Drive
6 Speed
Frame Type
Mild steel, tubular frame, rectangular section backbone, stamped, cast, and forged junctions, MIG welded, aluminum forged fender supports
Suspension - Front
Single cartridge 43 mm inverted with aluminum fork triple clamps, triple rate spring
Suspension - Rear
Hidden, free piston, coil-over monoshock, 43mm stroke, toothless hydraulic pre-load adjustment
Lean Angle
27.4°
Rake
30°
Swingarm
Mild steel, tubular sections, stamped x-member, forged axle junctions, MIG welded, removable belt spacer
Trail
150 mm / 5.9 in
Wheel Travel - Front
130 mm / 5.1 in
Wheel Travel - Rear
86 mm / 3.4 in
Brakes - Front
Single 300 mm discs, 4 piston fixed caliper
Brakes - Rear
Single 292 mm disc, 2 piston floating caliper
ABS
Standard
Tyres - Front
130/70B18 63H BW
Tyres - Rear
180/70B16 77H BW
Wheels
Black, machine highlighted, Mantis cast aluminum
