Displacement
1868 cc / 114 cu in
Engine Detail
Four stroke, V-Twin, Milwaukee-Eight 114, Pushrod-operated, overhead valves with hydraulic, self-adjusting lifters, 4 valves per cylinder
Bore x Stroke
102 x 114 mm
Compression Ratio
10.5:1
Cooling System
Air cooled
Exhaust
Black, 2-1-2 dual exhaust with tapered mufflers
Fuel Induction
Electronic Sequential Port Fuel Injection (ESPFI)
Ignition
Single-fire, non-wasted, map-controlled spark ignition
Lubrication
Pressurized, dry-sump with oil cooler
Starter
Electric
Clutch
Hydraulically actuated 9 plate wet, Assist & Slip
Final Drive
Belt
Gear Ratios
1st 9.593 2nd 6.65 3rd 4.938 4th 4 5th 3.407 6th 2.875
Primary Drive
Chain, 34/46 ratio
Frame Type
Mild steel; tubular frame; two-piece stamped and welded backbone; cast and forged junctions; twin downtubes; bolt-on rear frame with forged fender supports; MIG welded Swingarm Mild steel; two-piece drawn and welded section; forged junctions; MIG welded
Suspension - Front
49 mm forks, Dual Bending Valve
Suspension - Rear
Premium low height hand-adjustable rear shocks
Lean Angle
32°
Wheel Travel - Front
117 mm / 4.6 in
Wheel Travel - Rear
54.6 mm / 2.15 in
