Key Specifications
Engine
Four stroke, 90° °L° twin cylinder, DOHC, desmodromic 4 valve per cylinder.
Power
150.8 kW / 205 hp @ 10500 rpm
Torque
144.6 Nm / 14.7 kgf-m / 106.7 lb-ft @ 8750 rpm
Weight
190.5 kg / 420 lbs
Fuel Capacity
17 Litres / 4.5 US gal / 3.7 Imp gal
Advertisement
Full 2015 Ducati 1299S Panigale Specifications
Year
2015
Make Model
Ducati 1299S Panigale
Seat Height
830 mm / 32.7 in
Wheelbase
1437 mm / 56.57 in
Height
1130 mm / 44.1 in
Length
2060 mm / 81.1 in
Wet Weight (kg)
190.5
Dry Weight (kg)
166.5
Dry Weight
166.5 kg / 367 lbs
Fuel Capacity
17 Litres / 4.5 US gal / 3.7 Imp gal
Wet Weight
190.5 kg / 420 lbs
Displacement
1285 cc / 78.4 cub in
Engine Detail
Four stroke, 90° °L° twin cylinder, DOHC, desmodromic 4 valve per cylinder.
Bore x Stroke
116 x 60.8 mm
Compression Ratio
12.6:1
Cooling System
Liquid cooled
Emissions
Euro 3
Exhaust
2-1-2 titanium system with catalytic converter and 2 lambda probes. Twin stainless steel mufflers with aluminium end caps
Fuel Induction
Mitsubishi EFI, twin injectors per cylinder, full ride-by-wire elliptical throttle bodies
Ignition
Digital CDI
Lubrication
Wet sump
Starter
Electric
Clutch
Slipper and self-servo wet multiplate clutch with hydraulic control
Final Drive
Chain 525; front sprocket 15, rear sprocket 39
Gear Ratios
1st 37/15 / 2nd 30/16 / 3rd 27/18 / 4th 25/20 / 5th 24/22 / 6th 23/24
Primary Drive
Straight cut gears, ratio 1.77:1
Transmission / Drive
6 Speed with Ducati Quick Shift
Frame Type
Monocoque aluminum
Suspension - Front
Öhlins NIX30, 43mm fully adjustable USD fork with TiN treatment. Electronic compression and rebound damping adjustment with semi-active mode
Suspension - Rear
Fully adjustable Öhlins TTX36 unit. Electronic compression and rebound damping adjustment. Adjustable linkage: Progressive/flat. Aluminum single-sided swingarm, 4-point adjustable pivot.
Rake
24°
Steering Lock
48°
Trail
96 mm / 3.78 in
Wheel Travel - Front
120 mm / 4.72 in
Wheel Travel - Rear
130m m / 5.12 in
Brakes - Front
2 x 330 mm Semi-floating discs, radially mounted Brembo Monobloc EVO M50 4-piston calipers with cornering ABS Bosch 9.1 MP
Brakes - Rear
Single 245 mm disc 2 piston caliper with cornering ABS
Tyres - Front
120/70 ZR17 Pirelli Diablo Supercorsa SP
Tyres - Rear
200/55 ZR17 Pirelli Diablo Supercorsa SP
Wheels - Front
3-Spoke forged light alloy 3.50" x 17"
Wheels - Rear
3-Spoke forged light alloy 6.00" x 17"
