BMW CE04 Specs
2022 - 2023
• 2 variants
BMW has built the CE04, a scooter, across 2 variants since 2022, most recently updated for 2023. Under the tank sits a permanent-magnet liquid-cooled synchronous motor. It makes 20 hp at peak. Torque tops out at 61 Nm.
About the BMW CE04
Documented here are the full technical specifications for the BMW CE04, a Scooter motorcycle with a production run from 2022 to 2026. Specification data includes engine type and displacement, maximum power and torque output, transmission details, frame construction, suspension travel front and rear, brake types and rotor dimensions, tyre sizes, and overall weight and dimension figures. Select a year above to view the complete spec sheet for that model year.
BMW CE04 by Year
Spec Evolution
How key specs changed across production years.
No numeric spec data available for this model.
|
Specification
|
2022
|
2023
|
2026
|
|
Comments
|
Three Ride Modes (Eco, Rain, Road). Keyless. 8.5 kWh 148V lithium-ion battery. 40 lithium-ion battery cells. Charging 3.5 hours to 80%, with quick charger 65 min. | Three Ride Modes (Eco, Rain, Road). Keyless. 8.5 kWh 148V lithium-ion battery. 40 lithium-ion battery cells. Charging 3.5 hours to 80%, with quick charger 65 min. Three Ride Modes. ASC. | - |
|
Seat Height
|
855 mm / 33.7 in. | 780 mm / 30.7 in. ↓ | 780 mm (comfort seat: 800 mm) / 30.7 in (31.5 in) |
|
Frame Type
|
Steel double loop | Steel double loop | Double loop steel frame |
|
Brakes - Front
|
Double disc. ABS. Floating discs. 4-piston calipers. | Double disc. ABS. Floating discs. 4-piston calipers. | 2 x 265 mm disc brake, 4-piston fixed caliper ↓ |
|
Wheelbase
|
1675 mm / 65.9 in. | 1675 mm / 65.9 in. | 1675 mm / 65.9 in |
|
Brakes - Rear
|
Single disc. ABS. Floating disc. 1-piston floating calipers. | Single disc. ABS. Floating disc. 1-piston floating calipers. | Single 265 mm disc brake, 1-piston floating caliper ↑ |
|
Suspension - Front
|
Single-bridge telescopic forks | Single-bridge telescopic forks | Single-bridge telescopic fork |
|
Suspension - Rear
|
Single-sided swing arm/central spring strut | Single-sided swing arm/central spring strut | Single-sided swing arm, directly pivoted shock absorbe |
|
Final Drive
|
Belt (final drive) | Belt (final drive) | Toothed belt and gearbox with fixed transmission |
|
Height
|
1150 mm / 45.3 in. | 1150 mm / 45.3 in. | 1150 mm / 45.3 in |
|
Length
|
2285 mm / 90.0 in. | 2285 mm / 90.0 in. | 2285 mm / 90 in |
|
Tyres - Front
|
120/70-R15 | 120/70-R15 | 120/70 R15 |
|
Width
|
947 mm / 37.3 in. | 855 mm / 33.7 in. ↓ | 855 mm / 33.7 in |
|
Gearbox
|
1-speed | 1-speed | Single-speed transmission, integrated into electrical machine housing |
|
Trail
|
120 mm / 4.7 in. | 120 mm / 4.7 in. | 120 mm / 4.7 in |
|
Wheel Travel - Front
|
100 mm / 3.9 in. | 100 mm / 3.9 in. | 110 mm / 4.3 in ↑ |
|
Wheel Travel - Rear
|
92 mm / 3.6 in. | 92 mm / 3.6 in. | 92 mm / 3.6 in |
|
Max Torque
|
61.0 Nm (6.2 kgf-m or 45.0 ft.lbs) @ 4900 Revolutions | 61.0 Nm (6.2 kgf-m or 45.0 ft.lbs) @ 4900 Revolutions | 62 Nm / 45.7 lb-ft @ 1500 rpm ↑ |
